RPDU OUTLET MONITORED 20A 12 5-20R BLUE

Name: RPDU OUTLET MONITORED 20A 12 5-20R BLUE
Brand: VERTIV - GEIST - CTO & ETO
SKU: HJ8484
Price: 1123.65 USD
Availability: InStock

VERTIV - GEIST - CTO & ETO

PCN#

HJ8484

MFG#

NR30202-B

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$1,123.65

Extended & Accidental Damage Protection Plans Available Details

3-Year $143.99

2-Year $107.99

Free Shipping

Estimated Shipment:

Product Highlights:

Monitored
NEMA 5
20P
12 x NEMA 5
20R
120 V AC
Network (RJ
45)
10 ft Cord Length
Horizontal
Rack
mountable
Hot
swappable
TAA Compliant

Product Condition: New and Factory Fresh

Limited Warranty3 YearAdditional Warranty Information5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years

Shipping Weight: 10 lbs.

Geist rPDU MNR3E1R5-12S203-2ST5A0H10-S 12-Outlets PDU

Overview

Tech Specs

Specifications

Manufacturer	Vertiv
Manufacturer Part Number	NR30202B
Manufacturer Website Address	http://www.vertiv.com/
Brand Name	Geist
Product Series	rPDU
Product Model	MNR3E1R5-12S203-2ST5A0H10-S
Product Name	rPDU MNR3E1R5-12S203-2ST5A0H10-S 12-Outlets PDU
Marketing Information	Upgradeable Outlet Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of outlet level power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs. Benefits Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime. Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime. Fault-Tolerant Every unit is 100% tested for reliability and functionality. Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a break in the network chain occurs. Supports up to 40 rPDUs. Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices.
Product Type	PDU

Technical Information

PDU Type	Monitored
Plug/Connector Type	NEMA 5-20P
Plug/Connector Detail	1 x NEMA 5-20P
Receptacle Type	NEMA 5-20R
Receptacle Detail	12 x NEMA 5-20R
Features	LED Display

Power Description

Input Voltage	120 V AC
Input Voltage Range	100 V AC - 120 V AC
Output Voltage	120 V AC
Power Rating (Watt)	1900 W
Input Current	20 A
Input Frequency	60 Hz

Management

DHCP
HTTP
HTTPS
IPv4
IPv6
LDAP
NTP
RADIUS
RSTP
SSH
SMTP
SNMP (v1/v2c/v3)
Syslog
TACACS+
Modbus TCP
CSV datalog
JSON API
JSON datalog

Interfaces/Ports

Network (RJ-45)

Yes

Physical Characteristics

Product Color	Blue
Mounting Orientation	Horizontal
Mount Type	Rack-mountable
Form Factor	Hot-swappable
Cord Length	10 ft
Height	1.7"
Width	17"
Depth	12"

Environmental Conditions

Maximum Operating Temperature

140°F (60°C)

Miscellaneous

Package Contents	rPDU MNR3E1R5-12S203-2ST5A0H10-S 12-Outlets PDU Adjustable Mount Brackets
Application/Usage	IT Equipment
Certifications & Standards	FCC Part 15 Class A UL & c-UL Listed 62368-1
Country of Origin	United States
TAA Compliant	Yes
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	3 Year
Additional Warranty Information	5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
