Tripp Lite by Eaton PDU 18.7kW 200-240V 3PH Monitored PDU - LX Interface Gigabit 36 C13 Outlets IEC 309 60A Blue Input LCD 1.8 m Cord 0U 1.8 m Height TAA

Name: Tripp Lite by Eaton PDU 18.7kW 200-240V 3PH Monitored PDU - LX Interface Gigabit 36 C13 Outlets IEC 309 60A Blue Input LCD 1.8 m Cord 0U 1.8 m Height TAA
Brand: TRIPP LITE
SKU: 4AU193
Price: 1576.97 USD
Availability: InStock

TRIPP LITE

PCN#

4AU193

MFG#

PDU3EVN6G60C

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$1,576.97

Extended & Accidental Damage Protection Plans Available Details

2-Year $145.99

3-Year $194.99

Free Shipping

Estimated Shipment:

Product Highlights:

Monitored
IEC 60309 60A BLUE (3P+E)
36 x IEC 60309 C13
230 V AC
Network (RJ
45)
0U
Vertical
Rack Mount
Rack
mountable
TAA Compliant

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 26 lbs.

Tripp Lite by Eaton 18.7kW 200-240V 3PH Monitored PDU - LX Interface, Gigabit, 36 C13 Outlets, IEC 309 60A Blue Input, LCD, 1.8 m Cord, 0U 1.8 m Height, TAA

Overview

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	PDU3EVN6G60C
Manufacturer Website Address	https://tripplite.eaton.com/
Brand Name	Tripp Lite by Eaton
Product Model	PDU3EVN6G60C
Product Name	PDU3EVN6G60C 36-Outlet PDU
Marketing Information	3-Phase PDU Distributes and Monitors Network-Grade Power Recommended for data centers, server rooms and network closets, the 18.7kW PDU3EVN6G60C provides real-time remote monitoring of voltage and load levels via built-in network connection. A six-foot (1.8-meter) cord with IEC 309 60A Blue (3P+E) input plug connects the 3-phase PDU to a compatible AC power source, generator or protected UPS. The firmware can be easily upgraded to ensure the 0U PDU continues to perform at its best as connected equipment adds new features. 36 Outlets Dispense AC Power During normal operation, 36 C13 outlets distribute AC power to connected equipment. Each 200/208/240V outlet is accompanied by an LED that illuminates when the outlet is ramped up and ready to be used. The outlets are split into six load banks, each protected by a 20A circuit breaker that trips if the bank's connected load exceeds its maximum load rating. Plug-lock insert sleeves are included to prevent connected cables from becoming accidentally dislodged. Built-In LX Platform Network Management Card Allows Remote Access 24/7 The Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP. The 0U PDU can receive IP address assignments via DHCP server (automatic) or static (manual) method. Color Touchscreen LCD Offers Important Data at a Glance An easy-to-navigate color touchscreen LCD reports network data, including IP address, input current level per phase, and output current per load bank with ±1% billing-grade accuracy. It also generates a unique QR code to allow read-only access to the 3-phase PDU via mobile device. If an EnviroSense2 module is connected to the PDU, the LCD also displays its status and environmental data, such as temperature and humidity. Easy to Install Vertically in an EIA-Standard 19 in. Rack The 0U PDU mounts vertically using the included toolless mounting buttons or the included rack-mounting brackets. Spare buttons are also included. Use the included PDUMVROTATEBRKT kit to install the 3- phase PDU with outlets facing the rear for better airflow or equipment access. TAA-Compliant for GSA Schedule Purchases The PDU3EVN6G60C is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts. 2-Year Warranty The PDU3EVN6G60C is backed by a 2-year warranty, ensuring reliability and performance.
Product Type	PDU

Technical Information

PDU Type	Monitored
Phase	Three Phase
Plug/Connector Type	IEC 60309 60A BLUE (3P+E)
Receptacle Type	IEC 60309 C13
Receptacle Detail	36 x IEC 60309 C13
Protection Type	Overload Protection

Power Description

Input Voltage	230 V AC
Output Voltage	200 V AC 208 V AC 220 V AC 230 V AC 240 V AC
Power Rating (Watt)	18.70 kW
Input Current	60 A

Management

Protocols:

IPv4
IPv6
HTTP
HTTPS
SMTP
SNMPv1
SNMPv2
SNMPv3
Telnet
SSH
FTP
DHCP
NTP.

Interfaces/Ports

Network (RJ-45)

Yes

Physical Characteristics

Mounting Orientation	Vertical
Mount Type	Rack-mountable
Rack Height	0U
Height	70"
Width	2.2"
Depth	2.5"
Weight (Approximate)	18.65 lb

Miscellaneous

Package Contents	PDU3EVN6G60C 36-Outlet PDU Built-in LX Platform Interface Configuration Cable 36 x Plug-Lock Insert Sleeves Rack-Mounting Hardware Spare Mounting Buttons Mounting Bracket Accessory Owner's Manual
Country of Origin	Taiwan
TAA Compliant	Yes
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

2 Year
