8MP FULL-COLOR TURRET CAMERA 8MP FULL-COLOR TURRET CAMERA

Name: 8MP FULL-COLOR TURRET CAMERA 8MP FULL-COLOR TURRET CAMERA
Brand: TP-LINK SYSTEMS INC.
SKU: NP3632
Price: 125.4 USD
Availability: InStock

TP-LINK SYSTEMS INC.

PCN#

NP3632

MFG#

INSIGHT S485(2.8MM)

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$125.40

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $32.99

1-Year $24.99

Free Shipping

Estimated Shipment:

Product Highlights:

98.43 ft Infrared/Color Night Vision
H.265+, H.265, H.264, H.264+, H.264H, H.265M
3840 x 2160
2.80 mm Fixed Lens
25 fps
CMOS
Fast Ethernet
Ceiling Mount, Wall Mount
IP67
Water Proof, Weather Proof
Audio Support
Alarm Triggering, Vehicle Detection, Human Detection, Wide Dynamic Range, 3D Digital Noise Reduction, Noise Reduction, White Balance, Built
in Microphone, Day/Night, Mirror

Product Condition: New and Factory Fresh

Shipping Weight: 2 lbs.

TP-Link InSight InSight S485 8 Megapixel 4K Network Camera - Color - Turret

Overview

Tech Specs

Specifications

Manufacturer	TP-LINK Technologies Co., Ltd
Manufacturer Part Number	INSIGHT S485(2.8MM)
Manufacturer Website Address	http://www.tp-link.com/us
Brand Name	TP-Link
Product Line	InSight
Product Model	InSight S485
Product Name	VIGI 4MP Full-Color Turret Network Camera
Marketing Information	People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. Human & Vehicle Classification Distinguish humans and vehicles from other objects and receive more accurate event notifications. Smart Video Enhancement Technology True WDR:By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting. Smart IR:Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage. 3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details. White Balance:White Balance ensures neutral whites in an image, regardless of the lighting conditions. Efficient H.265+ Compression Technology H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Product Type	Network Camera

Technical Information

Recording Formats	4K
HD Recording	Yes
Night Vision	Yes
Night Vision Distance	98.43 ft
Night Vision Type	Infrared/Color
Number of IR LEDs	4
Infrared (IR) Cut-off Filter	Yes

Display & Graphics

Image Sensor Type	CMOS
Image Sensor Size	1/2.7"
Color Supported	Color
Field of View	Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134°
Effective Camera Resolution	8 Megapixel

Video

Video Formats	H.265+ H.265 H.264 H.264+ H.264H H.265M
Maximum Video Resolution	3840 x 2160
Maximum Frame Rate	25 fps

Audio

Audio Support

Yes

Lens

Lens Type	Fixed
Maximum Focal Length	2.80 mm
Lens Included	Yes
Lens Mount Type	M12-mount
Maximum Aperture	f/1.6

Exposure

Shortest Shutter Speed	1/10000 Second
Longest Shutter Speed	1/3 Second

Network & Communication

Connectivity Technology	Wired
Ethernet Technology	Fast Ethernet
Protocols	TCP/IP UDP ICMP HTTP HTTPS DHCP DNS RTSP NTP UPnP SSL/TLS FTP SFTP RTP IPv4 IPv6 ARP
Remote Management	Yes

Storage

Storage Type

Memory Card

Interfaces/Ports

Network (RJ-45)

Yes

Power Description

Maximum Power Consumption	12.50 W
Input Voltage	12 V DC
Power Source Type	DC PoE

Physical Characteristics

Mount Type	Ceiling Mount Wall Mount
Form Factor	Turret
Durability	Water Proof Weather Proof
Product Material	Metal
Height	3.3"
Width	4.4"
Length	4.4"
Diameter	4.4"
Weight (Approximate)	1.06 lb

Environmental Conditions

Minimum Operating Temperature	-22°F (-30°C)
Maximum Operating Temperature	140°F (60°C)
Minimum Storage Temperature	-40°F (-40°C)
Maximum Storage Temperature	140°F (60°C)
Maximum Operating Humidity (Non-condensing)	95%
Maximum Storage Humidity (Non-condensing)	95%

Miscellaneous

Features	Alarm Triggering Vehicle Detection Human Detection Wide Dynamic Range 3D Digital Noise Reduction Noise Reduction White Balance Built-in Microphone Day/Night Mirror
Package Contents	VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories
Ingress Protection Rating	IP67
