Middle Atlantic NEXSYS Series UPS Backup Power System with RackLink - 2000VA, 20 Amp

Name: Middle Atlantic NEXSYS Series UPS Backup Power System with RackLink - 2000VA, 20 Amp
Brand: MIDDLE ATLANTIC
SKU: JF6089
Price: 2790 USD
Availability: InStock

MIDDLE ATLANTIC

PCN#

JF6089

MFG#

UPX-RLNK-2000R-2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$2,790.00

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

2U Rack/Tower
AVR
8 Hour Recharge
3 Minute Stand
by
120 V AC Input
110 V AC, 120 V AC, 127 V AC Output
Pure Sine Wave
Serial Port
USB
LCD Display
8 x NEMA 5
20R

Product Condition: New and Factory Fresh

Limited Warranty3 YearAdditional Warranty Information2 Years Battery

Shipping Weight: 71 lbs.

Middle Atlantic NEXSYS Series 2RU 20 Amp UPS Backup Power System with NEXSYS - 2000VA

Overview

Tech Specs

Specifications

Manufacturer	Legrand Group
Manufacturer Part Number	UPXRLNK2000R2
Manufacturer Website Address	http://www.legrand.us
Brand Name	Middle Atlantic
Product Line	NEXSYS
Product Name	NEXSYS Series 2RU 20 Amp UPS Backup Power System with NEXSYS - 2000VA
Marketing Information	NEXSYS is built on a promise that we've kept for over two decades - more than half the life of the company - that our power products are designed, engineered, and built for AV. It's one thing to say it, it's another thing to prove it. And our NEXSYS Line Interactive UPS backups prove it, we promise. They are built with premium components to keep your AV systems running as smoothly as you'd expect. 2000VA and 20 amp. 8 Outlet UPS with Bank Control, (2) outlet banks with 4 outlets each. An Out-of-Box(y) Experience. Everything is assembled and connected right from the factory saving you time during your installations. Rack ears are pre-installed with the "4-Post" mounting brackets ready to be rack mounted even if you have a 3rd pair of rack rails. The battery is already connected so just plug it in. Customization is a Breeze. The NEXSYS Power Management Software on your PC allows you to customize and configure various settings and notifications if you don't like our default settings - we won't be offended. Set reminders or notifications for things like battery replacement, etc. via email or on the UPS. The IEC Input allows for better cable management of the power cord if shorter or longer cords are required. All UPSs include a 6' (1.8m) IEC power core. Easily locate the IP, MAC address, and device name via the front LCD screen. You can even see the battery installation date. Pure Power. All NEXSYS UPSs have a Pure Sine Wave output and AVR (automatic voltage regulation) providing the cleanest power to your connected equipment, especially the most sensitive equipment. Keep your power squeaky clean. Easily set specific thresholds to switch the unit to battery if the power quality isn't up to your standards. Swap it like it's hot. Hot-swappable battery from the front access panel for easy service without disrupting the system. RackLink Remote Management Built-In. The NEXSYS UPS is RackLink enabled out of the box and discoverable on the RackLink Discovery Tool on PC, Apple, or Android devices. Included RS232 port for control, (2) dry contact ports for alerts, 1 contact is defined to alert users of a battery switchover when the UPS loses utility power or hits a set threshold, 1 contact is defined to alert users when the battery level is low based on usage with customizable thresholds. Energy Star Certified.
Product Type	Line-interactive UPS

Technical Information

AVR	Yes
Plug/Connector Type	NEMA 5-20P
Receptacle Type	NEMA 5-20R
Receptacle Detail	8 x NEMA 5-20R
Dataline Protection	RJ-45
Cord Length	5.91 ft
Transfer Time	10 ms

Power Description

Load Capacity (VA)	2000 VA
Load Capacity (Watt)	1800 W
Input Voltage	120 V AC
Input Voltage Range	80 V AC - 145 V AC
Input Current	20 A
Output Voltage	110 V AC 120 V AC 127 V AC
Input Frequency	60 Hz
Waveform Type	Pure Sine Wave
Surge Energy Rating	1000 J

Display & Graphics

Display

LCD

Management

Network Management

Dry Contact
DB-9 RS-232
SmartSlot
Network Card

Interfaces/Ports

Serial Port	Yes
Network (RJ-45)	Yes
USB	Yes
EPO Port	Yes

Battery Information

DC System Voltage	48 V DC
Battery Chemistry	Lead Acid
Backup/Run Time (Full Load)	3 Minute
Backup/Run Time (Half Load)	10 Minute
Typical Battery Recharge Time	8 Hour
Hot Swappable	Yes
Replaceable Battery	Yes

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	9842.52 ft
Operating Humidity	95%
Sound Emission (A-Weighted)	50 dB(A)

Physical Characteristics

Color Family	Black
Product Color	Black
Height	3.5"
Width	19"
Depth	22"
Rack Height	2U
Form Factor	Rack/Tower
Weight (Approximate)	63.05 lb

Miscellaneous

Package Contents	NEXSYS 2000VA Rack/tower UPS 6' (1.8m) IEC Power Cord Network Card
Energy Star	Yes
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	3 Year
Additional Warranty Information	2 Years Battery
