Juniper EX4100-F-12T Ethernet Switch

Name: Juniper EX4100-F-12T Ethernet Switch
Brand: JUNIPER
SKU: 10HZ22
Price: 2610.63 USD
Availability: InStock

JUNIPER

PCN#

10HZ22

MFG#

EX4100-F-12T-TAA

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$2,610.63

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

12 Ports
Manageable
Gigabit Ethernet, 10 Gigabit Ethernet
10/100/1000Base
T, 10GBase
T, 10GBase
X
TAA Compliant
3 Layer Supported
Modular
55 W Power Consumption
Twisted Pair, Optical Fiber
1U High
Rack
mountable, Wall Mountable, DIN Rail Mountable
Lifetime Limited Warranty

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 1 lbs.

Juniper EX4100-F-12T Ethernet Switch

Overview

Tech Specs

Specifications

Manufacturer	Juniper Networks, Inc
Manufacturer Part Number	EX4100-F-12T-TAA
Manufacturer Website Address	http://www.juniper.net
Brand Name	Juniper
Product Series	EX4100-F
Product Model	EX4100-F-12T
Product Name	EX4100-F-12T Ethernet Switch
Marketing Information	The Juniper Networks® EX4100-F line of Switches offers a secure, cloud-ready portfolio of access switches ideal for enterprise branch, remote office, and enterprise campus networks. The EX4100-F switches combine the simplicity of the cloud, the power of Mist AI™, and a robust hardware foundation with high performance to deliver a differentiated approach to access switching in the cloud, mobile, and IoT era. With Juniper® Mist™ Wired Assurance, the EX4100-F line of Switches can be effortlessly onboarded, configured, and managed from the cloud. This simplifies operations, improves visibility, and ensures a much better experience for connected devices. Key features of the EX4100-F include: Cloud-ready, driven by Mist AI with Juniper Mist Wired Assurance and Marvis Virtual Network Assistant Ethernet VPN-Virtual Extensible LAN (EVPN-VXLAN) to the access layer Standards-based microsegmentation using group-based policies (GBPs) Flow-based telemetry to monitor traffic flows for anomaly detection, ability to measure packet delays and report drop reasons 10-member Virtual Chassis support Offering a full suite of Layer 2 and Layer 3 capabilities, the EX4100-F enables multiple deployments. As scaling requirements increase, Juniper's Virtual Chassis technology allows up to 10 EX4100-F switches to be seamlessly interconnected and managed as a single device, delivering a scalable, pay-as-you-grow solution for expanding network environments. The EX4100-F line consists of the following models: The EX4100-F-12T, which is a compact, fanless switch offering 12 x 1GbE non-PoE access ports. The EX4100-F-12P, which is a compact, fanless switch offering 12 x 1GbE Power over Ethernet Plus (PoE+) access ports and delivering up to 30 W per port with a total of 180 W of PoE power budget with an external power adapter. EX4100-F-12P can also be powered from an external 90 W power sourcing equipment (PSE) device connected via the uplink port. Additional 90 W of PoE budget is available if the second uplink port is connected to a PSE device. With external power adapter and the two uplink ports connected to 90 W external PSE, total PoE power budget supported is up to 300 W. The EX4100-F-24T, which offers 24 x 1GbE non-PoE access ports. The EX4100-F-24P, which offers 24 x 1GbE PoE+ access ports, delivering up to 30 W per port with an overall total 370 W of PoE power budget. The EX4100-F-48T, which offers 48 x 1GbE non-PoE access ports. The EX4100-F-48P, which offers 48 x 1GbE PoE+ access ports and delivers up to 30 W per port with an overall total PoE Power budget of 740 W.
Product Type	Ethernet Switch

Technical Information

Features

Fanless

Interfaces/Ports

Total Number of Network Ports	12
Uplink Port	Yes
Modular	Yes
Stack Port	Yes
Network (RJ-45)	Yes
Port/Expansion Slot Details	12 x Gigabit Ethernet Network 2 x 10 Gigabit Ethernet Uplink 4 x 10 Gigabit Ethernet Stack

Media & Performance

Media Type Supported	Twisted Pair Optical Fiber
Ethernet Technology	Gigabit Ethernet 10 Gigabit Ethernet
Network Technology	10/100/1000Base-T 10GBase-T 10GBase-X

I/O Expansions

Expansion Slot Type	SFP+
Number of SFP+ Slots	4

Network & Communication

Layer Supported	3
Networking Standards	IEEE 802.11ax IEEE 802.1ab IEEE 802.1ak IEEE 802.1p IEEE 802.1Q IEEE 802.1x IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3z IEEE 802.3ae IEEE 802.3x IEEE 802.3ax IEEE 802.3ah IEEE 802.1D IEEE 802.1s IEEE 802.1w IEEE 802.3ad

Management & Protocols

Manageable

Yes

Power Description

Power Source	Power Adapter
Power Consumption	55 W

Physical Characteristics

Compatible Rack Unit	1U
Form Factor	Rack-mountable Wall Mountable DIN Rail Mountable
Height	1.8"
Width	10.6"
Depth	9.7"
Weight (Approximate)	5.95 lb

Miscellaneous

TAA Compliant	Yes
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

Lifetime
