HP DL380 G10 PLUS 2U GOLD 5315Y 32GB RAM SAS 1 X 800 W

Name: HP DL380 G10 PLUS 2U GOLD 5315Y 32GB RAM SAS 1 X 800 W
Brand: HPE
SKU: HZ8118
Price: 8097.25 USD
Availability: InStock

HPE

PCN#

HZ8118

MFG#

P43357-B21

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$8,097.25

Extended & Accidental Damage Protection Plans Available Details

2-Year $462.99

3-Year $582.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel C621A Chip
2 Processor Support
2 TB RAM Support
DDR4 SDRAM
Up to 16 MB Graphic Card
10 Gigabit Ethernet
8 x SFF Bay(s)
Hot Swappable Bays
1 x 800 W
Intel Optane Memory Ready

Product Condition: New and Factory Fresh

Shipping Weight: 40 lbs.

HPE ProLiant DL380 G10 Plus 2U Rack Server - 1 x Intel Xeon Gold 5315Y 3.20 GHz - 32 GB RAM - 12Gb/s SAS Controller

Overview

Tech Specs

Specifications

Manufacturer	Hewlett Packard Enterprise
Manufacturer Part Number	P43357-B21
Manufacturer Website Address	http://www.hpe.com
Brand Name	HPE
Product Line	ProLiant
Product Series	DL380 G10 Plus
Product Name	ProLiant DL380 G10 Plus Server
Marketing Information	Adaptable for diverse workloads and environments, the secure 2P 2U HPE ProLiant DL380 Gen10 Plus delivers world-class performance with the right balance of expandability and scalability. Designed for supreme versatility and resiliency while being backed by a comprehensive warranty make it ideal for multiple environments from Containers to Cloud to Big Data. Standardize on the industry's most trusted compute platform.
Product Type	Server

Processor

Number of Processors Supported	2
Number of Processors Installed	1
Processor Manufacturer	Intel
Processor Type	Xeon Gold
Processor Generation	3rd Gen
Processor Model	5315Y
Processor Core	Octa-core (8 Core)
Processor Speed	3.20 GHz
Cache	12 MB

Chipset

Chipset Manufacturer	Intel
Chipset Model	C621A

Memory

Standard Memory	32 GB
Maximum Memory Supported	2 TB
Memory Technology	DDR4 SDRAM
Memory Clock Speed	3.20 GHz
Error Checking	ECC
Total Number of Memory Slots	32.0
Number of Occupied Memory Slots	1
Intel Optane Memory Ready	Yes
Signal Processing	Registered (Buffered)

Storage

Number of Hard Drives	No
Optical Drive Type	No

Controllers

Controller Type	12Gb/s SAS
Controller Model	P408i-a/2GB
RAID Supported	Yes

I/O Expansions

Number of Total Expansion Bays	8
Number of Internal 2.5" Bays	8
Number of SFF Bays	8
Hot Swappable Bays	Yes
Total Number of Expansion Slots	3.0
PCI Express x8 (Gen 3.x) Slots	2
PCI Express x16 (Gen 3.x) Slots	1
PCI Express Details	PCI-Express 4.0 Slots 3-slots (x8, x16, x8) as standard

Display & Graphics

Graphics Memory Capacity

16 MB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

Interfaces/Ports

Total Number of USB Ports	5
Number of USB 3.0 Ports	3
Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	2
VGA	Yes
Number of VGA Ports	1
Remote Management	Yes
Remote Management Controller	HPE iLO Remote Management Network Port
DisplayPort	Yes
Number of DisplayPorts	1

Operating System

Operating System Supported	Windows Server 2016 Windows Server 2019 SUSE Linux Enterprise Server 12 SP5 SUSE Linux Enterprise Server 15 SP2 Red Hat Enterprise Linux 7.9 Red Hat Enterprise Linux 8.2 Ubuntu 20.04 LTS
Operating System	No

Power Description

Number of Power Supplies Supported	2
Number of Power Supplies Installed	1
Plug/Connector Type	C13/C14
Maximum Power Supply Wattage	800 W
Hot Swappable Power Supply	Yes

Physical Characteristics

Form Factor	Rack
Rack Height	2U
Height	3.4"
Width	17.5"
Depth	28"
Weight (Approximate)	63.43 lb

Miscellaneous

Security Features

UEFI Secure Boot and Secure Start support
Tamper-free updates - components digitally signed and verified
Immutable Silicon Root of Trust
Ability to rollback firmware
FIPS 140-2 validation
Secure erase of NAND/User data
Common Criteria certification
TPM (Trusted Platform Module) 1.2 option
Configurable for PCI DSS compliance
TPM (Trusted Platform Module) 2.0 option
Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
Bezel Locking Kit option
Support for Commercial National Security Algorithms (CNSA)
Chassis Intrusion detection option
Secure Recovery - recover critical firmware to known good state on detection of compromised firmware
