Cisco Barebone System - Blade - 2 x Processor Support

Name: Cisco Barebone System - Blade - 2 x Processor Support
Brand: CISCO
SKU: XK4705
Price: 4394.67 USD
Availability: InStock

CISCO

PCN#

XK4705

MFG#

UCSB-EX-M4-1C

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$4,394.67

Extended & Accidental Damage Protection Plans Available Details

2-Year $331.99

3-Year $446.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel C602J Chip
3 TB DDR3 SDRAM Maximum RAM Support
48.0 Total Memory Slots
12Gb/s SAS RAID Supported Controller
Matrox G200e 8 MB Graphic(s)
Processor Support (Xeon)
Windows Server 2012 Standard, Windows Server 2012 Datacenter, Windows Server 2012 R2 Standard, Windows Server 2012 R2 Datacenter, Red Hat Enterprise Linux 6 Supported Operating System
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 YearAdditional Warranty Information Three-year parts coverage. Next business day (NBD) onsite parts replacement eight hours a day, five days a week. 90-day software warranty on media.

Shipping Weight: 1 lbs.

Cisco Barebone System - Blade - 2 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCSBEXM41C
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	B260 M4
Product Name	UCS B260 M4 Barebone System
Marketing Information	The Cisco® UCS B260 M4 High-Performance Blade Server is a two-socket, full-width blade server supporting the Intel® Xeon® E7-8800 v2, E7-4800 v2, and E7-2800 v2 series processor family CPUs, with up to 3 terabytes (TB) of double-data-rate 3 (DDR3) memory in 48 slots, up to two small form factor (SFF), hot-swappable drive bays for hard disk drives (HDDs) or solid state drives (SSDs), two dual-port and one quad-port mezzanine slots. These slots leverage the UCS virtual interface card (VIC) technology for up to 160 Gbps aggregate I/O bandwidth. The Cisco UCS B260 M4 server is designed to power the most demanding enterprise applications.
Product Type	Barebone System

Processor

Number of Processors Supported	2
Processor Supported	Xeon
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C602J

Memory

Maximum Memory Supported	3 TB
Memory Technology	DDR3 SDRAM
Total Number of Memory Slots	48.0

Storage

Supported Storage Drive Interfaces

SAS-3

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes
RAID Levels	0, 1

Display & Graphics

Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200e
Graphics Memory Capacity	8 MB

I/O Expansions

Number of Total Expansion Bays	2
Total Number of Expansion Slots	3.0

Operating System

Operating System Supported

Windows Server 2012 Standard
Windows Server 2012 Datacenter
Windows Server 2012 R2 Standard
Windows Server 2012 R2 Datacenter
Red Hat Enterprise Linux 6

Physical Characteristics

Form Factor	Blade
Height	2"
Width	17.2"
Depth	25.5"
Weight (Approximate)	32.85 lb

Warranty

Limited Warranty	3 Year
Additional Warranty Information	Three-year parts coverage. Next business day (NBD) onsite parts replacement eight hours a day, five days a week. 90-day software warranty on media.
