Black Box DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port

Name: Black Box DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port
Brand: BLACK BOX
SKU: UP7408
Price: 2928.18 USD
Availability: InStock

BLACK BOX

PCN#

UP7408

MFG#

ACXC8

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$2,928.18

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

7 Computer(s)
1 Local User(s)
47 Hz, 63 Hz
10 x Network (RJ
45)
Rack
mountable, Desktop
TAA Compliant

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 7 lbs.

Black Box DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port

Overview

Tech Specs

Specifications

Manufacturer	Black Box Corporation
Manufacturer Part Number	ACXC8
Manufacturer Website Address	http://www.blackbox.com
Brand Name	Black Box
Product Line	ServSwitch
Product Name	DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port
Marketing Information	The DKM Matrix switch enables switching between computers and remote consoles. The DKM Compact switch is available in CATx and Fiber and in port sizes of 8, 16, 32, 48, 64 and 80. The DKM 64 and 80 port switches offer hybrid interfaces that support both CATx and Fiber. CATx endpoints can be extended up to 400 feet (122 m) and Fiber endpoints can be extended up to 6.2 miles (10 km). Each port on the DKM is agnostic and can support a transmitter or receiver. The DKM features instantaneous switching between sources using the same video resolution. Users can interact with this KVM switch via hotkeys, OSD, eternal Java Utility, or an API interface. The DKM can easily be cascaded to support future expansion in the event that every port is in use. The DKM solution features transmitter and receiver endpoint options that can support DisplayPort, DVI-D, DVI-I, HDMI, VGA, USB HID, USB 2.0, Analog Audio, Digital Audio, RS232, and RS422. Black Box can also help you support legacy interfaces such as Component, Composite, S-Video, RGB Video, even with PS/2 keyboards and mice. The DKM transmitters and receivers support CATx or single-mode or Multi-mode Fiber which interfaces with the DKM FX KVM Switch.
Packaged Quantity	1
Product Type	KVM Switchbox

Technical Information

Number of Computers Supported	7
Number of Local Users Supported	1
Maximum Operating Distance	400 ft

Interfaces/Ports

Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	10

Power Description

Input Current	700 mA
Input Voltage	120 V AC 230 V AC
Input Voltage Range	88V AC to 264V AC
Frequency	47 Hz 63 Hz

Physical Characteristics

Form Factor	Rack-mountable Desktop
Height	1.7"
Width	8.8"
Depth	5.8"
Weight (Approximate)	4.06 lb

Miscellaneous

Package Contents	DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port 1 x US Power Cord 1 x RJ45/DB9 Adapter 4 x Rubber Feet User Manual 1 x 19" Rack Mount
Environmentally Friendly	Yes
Environmental Certification	WEEE RoHS
Country of Origin	Germany
TAA Compliant	Yes

Warranty

Limited Warranty

2 Year
